Flameless Venting for Elevators.
The Q-Ball® E guarantees safe explosion pressure relief in the operating area. Efficient cooling inside the Q-Ball® E prevents the flames from escaping and eliminates pressure effects as a result of the explosion. The connecting dimensions of the Q-Ball® E perfectly complement the standard sizes of mechanical conveyors such as elevators. This avoids the need for work-intensive adjustments of the flanges. Due to the low weight of the Q-Ball® E, any reinforcements of the conveyor‘s shaft also become unnecessary. With the newly developed principle of full body flameless venting, the Q-Ball® E ensures maximum relief efficiency. The necessary relief area can thus be reduced to a minimum.
The Q-Ball® E is suitable for flameless venting of mechanical conveyors with low design strength such as elevators. Explosions with KSt values up to 200 bar × m/s can be handled.
- Maximum venting efficiency through a full body flameless venting.
- Easy maintenance through an integrated inspection opening.
- Integrated signalling for a reliable monitoring.
- Can be utilized flexibly indoors and outdoors.
- Easy retrofitting of existing vent panels installations possible.
The special stainless steel mesh filter inlet developed by REMBE® cools the hot flame gases extremely efficiently (up to 1.500 °C (2.732 °F). This reduces the volume of gas ejected and extinguishes the explosion.
Dimensions and Weight
|180 x 420 mm||400 mm||400 mm||570 mm||15 kg|
|205 x 610 mm||480 mm||420 mm||780 mm||20 kg|
|305 x 610 mm||500 mm||520 mm||780 mm||25 kg|
- animal feed productions
- aspiration plants
- food production
- mills and grinding plants
- spray dryers
- wood processing
Meets the requirements of NFPA 68
ATEX EC type
examination certificate no. GEX 19 ATEX 1001X
The combination of the Q-Ball® E and isolation systems prevents pressure waves and flames propagating to other parts of the plant.
